Back Fixing
For different facade structure and curtain wall design requirements, IFL provides corresponding installation system solutions and fixing components. IFL also provides customized machining options for terracotta panels and baguettes, including drilling, backside jogs, horizontal and vertical cutting, miter cut for corner, etc.
IFL common installation system for terracotta ventilated facades:
IFL – T30mm Facade Supporting System
This supporting system is suitable for all kinds of IFL terracotta rainscreen facade panels. It is easy to install, and a single terracotta panel can be replaced separately. Panels can be oriented in horizontal and vertical layout by adjust the supporting system.
IFL – T18mm Facade Supporting System
This installation system is suitable for The TERRA-Range of lightweight terracotta panels (Thickness: 15-18mm) that have back extruded grooves for installation. The system requires less depth of ventilated cavity.
Baguette & Louver Fixing System
IFL’s basic installation system for terracotta baguettes includes side fixing and back fixing solution. Baguettes can be installed horizontally, vertically or at any specific angle.
More Terracotta Rainscreen Façade Details for Mounting System are available on request.
Panel T18mm Fixing
The supporting frame system and fixing clips used for thin, fluted terracotta facade tiles. IFL provides customized mechanical, clip-based solutions for specific project.
Panel T30mm Fixing
IFL fixing components for terracotta suspended ventilated facade (double-skin panel in thickness: 20,22,24,30,40 mm). Both horizontal and vertical support systems can be designed and provided.
Baguette Fixing
IFL offers side and back fixing systems for terracotta baguette and louver products. Galvanized steel, aluminum and architectural stainless steel attachment systems can be customized according to facade structural demand.
